Only 7 In-Stock Remaining.
Mechanical Features
- 7mm output shaft with doubleflat outputs
- Secondary output shaft (D) for encoders (not meant for rotational loads)
- Builtin safety ratchet clutch set for 60 in*oz torque (easily modified for full lockedup operation)
- Builtin mounting holes
- 55x48x22.7mm (2.17x1.89x0.894)
- 31.4 grams (1.11oz)
- 36VDC nominal operation
3V Features
- 24RPM
- 48.6 in*oz torque
- 40mA freerunning current
- 400mA stall current
