4000 counts digital display
Auto ranging
Auto power off Overload protections
Safety input jacks Safety test leads
Safety: EN610101 CATIII 600V CE approved
Dimensions: 165mm(H)×78mm(W)×42.5mm(D)
Weight: Approx. 285g
RPM: 600 4000 4000 12000 ± 2.0%
Dwell Angle: 4 5 6 8 cylinders ± 2.0%
Duty cycle: 0 90% > 100μs < 100ms ± 2.0%
DC Volts: 400mV 4V 40V 400V 600V ± 1.0%
AC Volts:400mV 4V 40V 400V 600V ± 2.0%(50 500Hz)
DC Current: 400μA 4000μA 40mA 400mA 10A ± 2.0%
AC Current: 400μA 4000μA 40mA 400mA 10A ±2.5% (50 500Hz)
Resistance: 400Ω 4k 40k 400k 4M 40MΩ ± 1.5%
Frequency: 10 Hz 400kHz ± 0.1%
Temperature: 20°C to 1000°C 4°F to 1832°F ± 2.0%
KType thermocouple
Diode Test Continuity Test Data Hold
Resolution: 1RPM 0.1mV 0.1μA 0.1Ω 1Hz 0.1°C 0.1°F
